• 311 FNM/PING Series

    311 FNM/PING Series

    • TERMINAL MATERIAL : COPPER RATE
    • ALTERNATIVE INSULATOR:
      FUNNEL BARREL EASY ENTRY
      POLYCARBONATE INSULATOR
    • PC : FEM, PGTS
Please Click products below, and click Add to Inquiry List for inquiry.
Photo Series Product Name Download Insulation
Color 		Wire Range Dimension(mm) TAB SIZE PACKING
POLYBAG 		Select
D1 D3 D4 H1 H2 T AWG(#) D2(mm)

311032 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 5.5 4.0 12.2 5.5 0.8 4 3.2 100/500/1000

311037 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 6.5 4.0 15.8 5.5 0.8 6 3.7 100/500/1000

311043 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 8.0 4.0 16.3 5.5 0.8 8 4.3 100/500/1000

311053 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 8.0 4.0 21.2 5.5 0.8 10 5.3 100/500/1000

311064 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 11.0 4.0 21.2 5.5 0.8 1／4 6.4 100/500/1000

311084 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 12.0 4.0 23.8 5.5 0.8 5／16 8.4 100/500/1000

311010 FNM/PING

Red AWG 22-16
0.5-1.5mm² 		1.8 14.5 4.0 25.2 5.5 0.8 3／8 10.0 100/500/1000
