• Pin Terminals-Non Insulated ( 圓針形裸端)

    Pin Terminals-Non Insulated ( 圓針形裸端)

    1.Maximum Electric Current: (最大電流)
       22-16AWG / 0.5-1.5mm²: 19A
       16-14AWG / 1.5-2.5mm²: 27A
       12-10AWG / 4-6mm²: 48A
    2.Terminal Body: Copper (端子材質: 紅銅)
    3.Insulation:  (護套材質: )
    4.Plating: Tin(表面處理: 鍍錫)

    NBT---Non-Insulated butted seam

    NB---Non-insulated brazed seam

  • Pin Terminals-Non Insulated ( 圓針形裸端)

    331

Please Click products below, and click Add to Inquiry List for inquiry.
Photo Series Product Name Download Insulation Color Wire Range mm2/Awg 适用 Dimension(mm/inch)主要尺寸 Packing 包 Select

331007

Red
0.5-1.5mm2 22-16AWG
 1.9(.075)/7.0(0276)/17(.669)/10(.394)/4.0(.157)/1.7(075)/0.75(.030)
1000/500

331007

Red
0.5-1.5mm2 22-16AWG
 1.9(.075)/9.0(.354)/19(.748)/10(.394)/4.0(.157)/1.7(075)/0.75(.030)
1000/500

331010

Red
0.5-1.5mm2 22-16AWG
 1.9(.075)/10.0(.394)/20(0787)/10(.394)/4.0(.157)/1.7(075)/0.75(.030)
1000/500

331019

Red
0.5-1.5mm2 22-16AWG
 1.9(.075)/12.0(.472)/22(.866)/10(.394)/4.0(.157)/1.7(075)/0.75(.030)
1000/500

335007

Blue
1.5-2.5mm2 16-14AWG
 1.9(.075)/7.0(0276)/17(.669)/10(.394)/4.5(.177)/2.3(.09)/0.8(.031)
1000/500

335009

Blue
1.5-2.5mm2 16-14AWG
 1.9(.075)/9.0(.354)/19(.748)/10(.394)/4.5(.177)/2.3(.09)/0.8(.031)
1000/500

335017

Blue
1.5-2.5mm2 16-14AWG
 1.9(.075)/17.0(.669)/27(1.062)/10(.394)/4.5(.177)/2.3(.09)/0.8(.031)
1000/500

335019

Blue
1.5-2.5mm2 16-14AWG
 1.9(.075)/12.0(.472)/22(.866)/10(.394)/4.5(.177)/2.3(.09)/0.8(.031)
1000/500

333027

Yellow
4-6mm2 12-10AWG
 2.7(.106)/15.0(.591)/28(1.102)/13.0(.512)/6.3(.248)/3.4(.134)/1.0(.039)
1000/500
